Toe clamps, Form A

04482_A

Toe clamps, Form A

Products
- Product overview
  - Flexible standard component system
    - Clamp straps Clamping devices
      - Side clamp
        Toe clamps
        Toe clamps, Form A

Item description/product images

DescriptionMaterial:Carbon steel.Version:Body tempered and black oxidised.
Jaw plate black oxidised and tempered on the edges.

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet 04482_A Toe clamps, Form A

Drawings

Toe clamps, Form A

Item selection/filter

Order No.	B	B1	B2	G	H1	H	H2	H3	J	L1	L	SW	Clamping force N	Tightening torque Nm	CAD	Acc.	Price	Order
04482-0808	65	45	25	M8	16	7,5	7	1,5	7	25	39,5	4	4000	8			137.23 €
04482-1210	85	60	35	M12	22	10	9	2	12	40	60	6	9000	26			182.97 €
04482-1614	100	70	40	M16	30	14	13	2	14	50	77	8	17000	60			259.22 €
