Spring plungers with hexagon socket and ball, stainless steel, inch
 03035 inch

Spring plungers with hexagon socket and ball, stainless steel,...

 go back

Item description/product images

 Show/filter all items
DescriptionMaterial:

Sleeve 1.4305.
Ball 1.4034.
Spring 1.4310.

Version:Bright. Ball hardened.Note:For the inch series, dimension D and S are in inches, all other dimensions are in mm.Special features:
Stainless steel
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
Datasheet 03035 inch Spring plungers with hexagon socket and ball, stainless steel, inch 253 kB

Drawings (total overview)

Spring plungers with hexagon socket and ball, stainless steel, inch

Spring plungers with hex socket and ball, stainless steel, standard spring force - inch

 More information

Drawings
Spring plungers with hex socket and ball, stainless steel, standard spring force - inch

Item selection/filter
Order No.

DD1HLSSpring force
initial pressure
F1 approx. N		Spring force
final pressure
F2 approx. N		CADAcc.PriceOrder
03035-AJ1/4-283,51151/8913 5.37 €
03035-A21/4-203,51151/8913 5.37 €
03035-A35/16-1851,5185/321530 5.82 €
03035-A43/8-1662233/162035 6.79 €
03035-A51/2-1382,5267/323055 9.06 €
03035-A65/8-11103,5335/1665125 14.33 €

Spring plungers with hex socket and ball, stainless steel, strong spring force - inch

 More information

Drawings
Spring plungers with hex socket and ball, stainless steel, strong spring force - inch

Item selection/filter
Order No.

DD1HLSSpring force
initial pressure
F1 approx. N		Spring force
final pressure
F2 approx. N		CADAcc.PriceOrder
03035-2AJ1/4-283,51151/82840 5.95 €
03035-2A21/4-203,51151/82840 5.95 €
03035-2A35/16-1851,5185/324773 6.44 €
03035-2A43/8-1662233/1666100 7.43 €
03035-2A51/2-1382,5267/3266120 9.95 €
03035-2A65/8-11103,5335/1690180 15.72 €
