Item description/product images

DescriptionMaterial:Thermoset PF 31.
Tapped bush, steel or stainless steel.
Version:Thermoset black, high-gloss polished.
Trivalent blue passivated steel or bright stainless steel.
Temperature range:Permanent application temperature 140 °C.
Temporary operating temperature max. 160 °C.
Assembly:From the rear.Special features:
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
 Datasheet 06901-01 Pull handles, oval plastic 116 kB


Pull handles, oval plastic

Item selection/filter

Order No.Component

06901-01-21000621steel1002113M6501139500 9.26 €
06901-01-21200621steel1202113M6501339500 9.86 €
06901-01-21280621steel1282113M6501419500 10.14 €
06901-01-21600825steel1602517M85517712500 12.74 €
06901-01-31000621stainless steel1002113M6501139500 13.50 €
06901-01-31200621stainless steel1202113M6501339500 14.43 €
06901-01-31280621stainless steel1282113M6501419500 15.23 €
06901-01-31600825stainless steel1602517M85517712500 17.70 €
